B24-Industrial Exhaust Fan
Stainless steel exhaust fan
Steel exhaust fan
B24-Specification
| MODEL | B24WSS | B24MSS | B24VSS | B24W | B24M | B24V |
| TYPE | Wall-mounted | Portable | Standing | Wall-mounted | Portable | Standing |
| MATERIAL | Stainless Steel | Stainless Steel | Stainless Steel | Steel | Steel | Steel |
| BLADE DIAMETER | 24 inch | 24 inch | 24 inch | 24 inch | 24 inch | 24 inch |
| MOTOR | 0.25HP | 0.25HP | 0.25HP | 0.25HP | 0.25HP | 0.25HP |
| AIR FLOW (Max.) | 5000 CFM | 5000 CFM | 5000 CFM | 5000 CFM | 5000 CFM | 5000 CFM |
| DRIVE | Belt | Belt | Belt | Belt | Belt | Belt |
| VOLTAGE | 3φ,220V/380V | 3φ,220V/380V | 3φ,220V/380V | 3φ,220V/380V | 3φ,220V/380V | 3φ,220V/380V |
| Customized | Customized | Customized | Customized | Customized | Customized | |
| NOISE | 77dB | 77dB | 77dB | 77dB | 77dB | 77dB |
| WEIGHT | 86 lbs | 97 lbs | 106 lbs | 86 lbs | 97 lbs | 106 lbs |
| DIMENSIONS | 72X37X72 cm | 72X50X87 cm | 72X50X130 cm | 72X37X72 cm | 72X50X87 cm | 72X50X130cm |
B24-Parts
Product specification may change, and the company’s specifications at the time of quotation shall prevail.
Product colors and styles are subject to the company’s latest styles, and pictures are for reference only.
